ART-VS: Adaptive Resolution Tiling for Vision Transformer Visual Servoing

Abstract

Visual servoing with self-supervised Vision Transformer features enables training-free robotic positioning that generalizes to unseen objects, but faces a trade-off: coarse patch descriptors are robust yet imprecise, while high-resolution features are precise but slow and memory-hungry. ART-VS resolves this with a two-phase, backbone-agnostic strategy: it servos at the ViT's native resolution for stable long-range alignment, then switches to a tiled high-resolution phase that matches features tile-locally for precise convergence. Without task-specific training, ART-VS reaches 95.4% convergence under perturbation (18.8 pp over prior ViT-based servoing, 14.4 pp over full-resolution processing) while delivering over 10× higher effective FPS at 27% lower VRAM. On a real robot it grasps unseen instances from a single reference image: 95/100 transparent bottles and 98/100 shoes, across four backgrounds.

Method

Coarse, then tiled

A single strategy that keeps the robustness of low resolution and recovers the precision of high resolution — without paying the quadratic cost of processing everything at once.

STEP 01

Initialization

Resolve in-plane rotation against the reference image; optionally isolate the target with a language prompt (LangSAM) plus a lightweight tracker (LightTrack) for cluttered scenes.

STEP 02

Coarse phase

Single-pass ViT encoding with global patch-to-patch correspondences at native resolution — robust to appearance change and large pose gaps.

STEP 03

Tiled refinement

Once mean error drops below τ = 0.20 (an 80% reduction), the image is split into non-overlapping tiles matched tile-locally — recovering full-resolution precision without quadratic cost.

Backbone-agnostic, validated on: DINOv2 DINOv3 AM-RADIO — all training-free.

ART-VS pipeline: initialization to coarse to tiled refinement — **Figure 2.** The ART-VS pipeline: initialization, coarse native-resolution servoing, and tiled high-resolution refinement.

Real robot

Grasping unseen objects

200 category-level trials from a single reference image per category: five unseen instances each of transparent bottles and shoes, across four backgrounds — plain wood, aluminium foil, kraft paper, and kitchen towel.

Transparent bottle — plain wood

Transparent bottle — aluminium foil

Transparent bottle — kraft paper

Transparent bottle — kitchen towel

Shoe — plain wood

Shoe — aluminium foil

Shoe — kraft paper

Shoe — kitchen towel

95/100

transparent bottles grasped

98/100

shoes grasped

4

backgrounds per category

1

reference image per category

Objects and backgrounds used in the grasping trials — **Figure 6.** Unseen bottle and shoe instances across the four evaluation backgrounds.

Failure cases

Honest failure modes from the paper's analysis — where ambiguous geometry or challenging optics push the match past its limits.

Near-symmetric bottle — ambiguous rotation

Specular reflection near convergence

Extreme initial viewpoint — ambiguous match

Simulation

Simulation benchmark

Perturbed Hollywood-poster scenes, 500 trials per method. ART-VS variants lead on convergence and precision while staying well within a real-time budget.

Method (perturbed)	Conv.%	Pos. (cm)	Orient. (°)	VRAM (MB)	FPS
AKAZE-IBVSclassical	64.8	0.09	0.08	—	1.7
ViT-VS DINOv2-308baseline	76.6	2.15	1.83	1230	14.4
ViT-VS DINOv3-1440full 1440p frame, no tiling	81.0	1.65	1.43	2431	0.9
ART-VS DINOv27×7 tiles	87.2	0.88	0.78	2174	10.5
ART-VS DINOv36×6 tiles · best convergence	95.4	1.01	0.88	1767	11.9
ART-VS AM-RADIO6×6 tiles · best precision	91.0	0.81	0.69	2779	6.8

The number in a baseline name is the ViT input resolution — e.g. DINOv2-308 and DINOv3-1440 process the frame at 308 px and at the full 1440p (1440×1080) resolution — whereas ART-VS “N×N” denotes the adaptive tiling grid used instead. FPS is the effective frame rate (total iterations / wall-clock time). Highlighted rows are ART-VS; bold marks the best convergence (95.4%) and the best positional / orientation precision (0.81 cm / 0.69°), reported over converged trials.

Watch

Supplementary video

The full supplementary video: method overview, simulation benchmarks, and real-robot grasping across all backgrounds.

Cite

Citation

ART-VS is accepted at IROS 2026. Until the proceedings appear, please cite the arXiv preprint.

BibTeX — arXiv preprint

@article{scherl2026artvs,
  title   = {ART-VS: Adaptive Resolution Tiling for Vision Transformer Visual Servoing},
  author  = {Scherl, Alessandro and Neuberger, Bernhard and Schwaiger, Simon and
             Mulero-P{\'e}rez, David and Muster, Lucas and Garc{\'i}a-Rodr{\'i}guez, Jos{\'e}},
  journal = {arXiv preprint arXiv:2606.19089},
  year    = {2026}
}
